The chipboard screw with flange head, TX star recess socket and partial thread.

PowerFast FPF II WTP BC

The fischer PowerFast FPF II WTP BC is an electrogalvanized, blue passivated screw with partial thread and inner star drive. The flange head with inner star TX drive guarantees a greater contraction effect as well as a significantly increased head pull-through resistance. The partially threaded version enables wooden elements to be pulled tightly together.

Varijante proizvoda

Download of image data

Varijante proizvoda

Approvals / Test reports

18 product variants

Diameter

Length

Drive

Thread length

Amount

GTIN (EAN-Code)

Legend = Permission Available— = Permission not Available

Viewed 18 of 18 variant (s)

Advantages

With flange head for greater contraction effect as well as significantly increased head pull-through resistance.
The increased thread pitch significantly reduces the installation time.
The three ribs on the tip, ensure a quick bite and pre-drilling.
The shank-miller in combination with the core-miller geometry is designed to reduce the installation torque.
The PowerFast II is suitable for use with fischer plugs (E.g DuoPower and UX) and recommended loads.

Applications

For use in load-bearing wooden constructions, for the connection of solid wood parts as well as glued laminated timber, cross laminated timber, etc.
For metal parts to wood, e.g. metal fittings, angles, beam shoes and other metal and wood connections.
Suitable for use with fischer plugs and recommended loads.

Building materials

Solid wood parts (soft wood and hard wood)
Glued-laminated timber
Cross-laminated timber
Veneer laminated timber
Similar glued wood components and woodbased panels

Detaljne informacije o građevinskom materijalu možete pronaći u dokumentu za registraciju.

Odobrenja

ETA-19/0175
DoP No. W0020

ETA Certification Document

pdf, ETA-19/0175

European Technical Assessment for fischer Power-Fast II screws for use in timber constructions

Napravljeno 19. 09. 2023.

DOP - Declaration of Performance

pdf, DoP No. W0020

Declaration of Performance for fischer Power-Fast II screws, fischer Power-Fast II - Chipboard screws, fischer Power-Fast II - Wood Construction screws

Napravljeno 10. 10. 2023.

Marketing Documents

pdf,

PowerFast II. The chipboard screw for fast and flexible applications.

ETA-approval
Diameter ( d )	5 mm
Length ( l )	50 mm
Drive	TX25
Thread length ( l_g )	30 mm
Amount	200 pcs
GTIN (EAN-Code)	4048962437324

ETA-approval
Diameter ( d )	5 mm
Length ( l )	60 mm
Drive	TX25
Thread length ( l_g )	36 mm
Amount	200 pcs
GTIN (EAN-Code)	4048962437331

ETA-approval
Diameter ( d )	5 mm
Length ( l )	80 mm
Drive	TX25
Thread length ( l_g )	45 mm
Amount	200 pcs
GTIN (EAN-Code)	4048962437348

ETA-approval
Diameter ( d )	5 mm
Length ( l )	100 mm
Drive	TX25
Thread length ( l_g )	60 mm
Amount	100 pcs
GTIN (EAN-Code)	4048962437355

ETA-approval
Diameter ( d )	5 mm
Length ( l )	120 mm
Drive	TX25
Thread length ( l_g )	70 mm
Amount	100 pcs
GTIN (EAN-Code)	4048962437362

PowerFast FPF II WTP BC

Varijante proizvoda

Prednosti / Opis proizvoda

Prijava i odobrenje

Uputstvo za montažu

Dokumenti za preuzimanje

ETA-approval
Diameter ( d )	6 mm
Length ( l )	60 mm
Drive	TX30
Thread length ( l_g )	36 mm
Amount	100 pcs
GTIN (EAN-Code)	4048962437379
