fischer Cantilever arm FMC 90 - 750

Name: fischer Cantilever arm FMC 90 - 750
Brand: fischer

Varijante proizvoda

Download of image data

Top Features

The graduated length assortment of the FMC cantilever arms allows an optimal adaptation to the respective application.
The stable base plate of the cantilever provides a secure hold for a load-bearing construction.
The completely hot-dip galvanised product range guarantees on-site processing without subsequent coating and simplifies and accelerates the assembly process sustainably.

Mounting profiles with welded base plate for fastening heavy duty pipelines

Advantages

The graduated length assortment of the FMC cantilever arms allows an optimal adaptation to the respective application.
The stable base plate of the cantilever provides a secure hold for a load-bearing construction.
The completely hot-dip galvanised product range guarantees on-site processing without subsequent coating and simplifies and accelerates the assembly process sustainably.

The cantilever arm FMC is the second basic element of the fischer massive channel system FMS and is suitable for fixing heavy pipeline routes along the wall. The cantilever arm is fastened directly to the substrate through the slotted holes in the base plate. fischer offers standard lengths of 500 - 1,500 mm, which avoids time-consuming cutting to length on site. This saves time and money. The hot-dip galvanised version is suitable for outdoor installations.

Properties

Material base plate: steel S235JR (material no. 1.0038) acc. to DIN EN 10025-2
Material profile: steel S355MC (material no. 1.0976) acc. to DIN EN 10149-2
Zinc plating: hot-dip galvanised

Length ( L )	750 mm
Width ( B )	230 mm
Height ( H )	230 mm
Thickness ( S )	15 mm
Max. recommended static load load case 1 ( F_rec )	16,4 kN
Max. recommended static load load case 2 ( F_rec )	8,2 kN
Max. recommended static load load case 3 ( F_rec )	16,4 kN
Amount	1 pcs
GTIN (EAN-Code)	4048962338683

fischer Cantilever arm FMC 90 - 750
